ADS8556IPM

ADS8556IPM Overview

This product is manufactured by Texas Instruments. The product can operate at a maximum temperature of SMD/SMT. LQFP-64 package/case type is utilized by this product. This product is equipped with 6 Channel for efficient performance. The sampling rate of this product is 630 kS/s. Single-Ended input type Interface Type: Parallel, Serial SAR architecture External, Internal is the reference type. This product requires an 4.5 V to 5.5 V for proper operation. The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. Tray packaging for easy dispensing The height of the product is 1.4 mm. 10 mm long Texas Instruments is a trusted brand for quality electronics ADS8556EVM is a versatile development platform for hardware and software The - 1 /2 LSB, ensuring accurate and precise analog-to-digital conversion. INL is within +/- 4 LSB Yes regarding Moisture Sensitivity 4.5 V to 5.5 V operating supply voltage range 251.7 mW ADCs - Analog to Digital Converters product type 160 of 100 Data Converter ICs as subcategory 1. 0.012088 oz of Unit Weight

ADS8556IPM Image

ADS8556IPM Specifications

• Manufacturer: Texas Instruments
• Product Category: Analog to Digital Converters - ADC
• RoHS: Y
• Series: ADS8556
• Mounting Style: SMD/SMT
• Package / Case: LQFP-64
• Resolution: 16 bit
• Number of Channels: 6 Channel
• Sampling Rate: 630 kS/s
• Input Type: Single-Ended
• Interface Type: Parallel, Serial
• Architecture: SAR
• Reference Type: External, Internal
• Analog Supply Voltage: 4.5 V to 5.5 V
• Digital Supply Voltage: 2.7 V to 5.5 V
• SNR - Signal to Noise Ratio: 91.5 dB
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Packaging: Tray
• Features: Daisy-Chainable, Oscillator
• Height: 1.4 mm
• Length: 10 mm
• Number of Converters: 6 Converter
• Power Consumption: 335 mW
• Width: 10 mm
• Brand: Texas Instruments
• Development Kit: ADS8556EVM
• DNL - Differential Nonlinearity: - 1 /2 LSB
• INL - Integral Nonlinearity: +/- 4 LSB
• Moisture Sensitive: Yes
• Operating Supply Voltage: 4.5 V to 5.5 V
• Pd - Power Dissipation: 251.7 mW
• Product Type: ADCs - Analog to Digital Converters
• Reference Voltage: 2.5 V
• SINAD - Signal to Noise and Distortion Ratio: 89.5 dB
• Factory Pack Quantity: 160
• Subcategory: Data Converter ICs
• Unit Weight: 0.012088 oz
