ADS9120IRGET

ADS9120IRGET Overview

This product is manufactured by Texas Instruments. The product can operate at a maximum temperature of SMD/SMT. VQFN-24 package/case type is utilized by this product. This product is equipped with 1 Channel for efficient performance. The sampling rate of this product is 2.5 MS/s. Differential input type Interface Type: SPI SAR architecture External is the reference type. This product requires an 1.8 V for proper operation. The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. Reel packaging for easy dispensing This device belongs to the High Speed ADC type. Texas Instruments is a trusted brand for quality electronics This product does not have a No Shutdown feature, ensuring continuous operation. The 0.25 LSB, ensuring accurate and precise analog-to-digital conversion. 0.01 % FS is 0.2%. INL is within 0.25 LSB Yes regarding Moisture Sensitivity 9 mW ADCs - Analog to Digital Converters product type 250 of 100 Data Converter ICs as subcategory THD is as low as - 101 dB. 1. 0.001566 oz of Unit Weight

ADS9120IRGET Image

ADS9120IRGET Specifications

• Manufacturer: Texas Instruments
• Product Category: Analog to Digital Converters - ADC
• RoHS: Y
• Series: ADS9120
• Mounting Style: SMD/SMT
• Package / Case: VQFN-24
• Resolution: 16 bit
• Number of Channels: 1 Channel
• Sampling Rate: 2.5 MS/s
• Input Type: Differential
• Interface Type: SPI
• Architecture: SAR
• Reference Type: External
• Analog Supply Voltage: 1.8 V
• Digital Supply Voltage: 1.65 V to 1.95 V
• SNR - Signal to Noise Ratio: 84 db
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Packaging: Reel
• Features: Daisy-Chainable, Oscillator
• Number of Converters: 1 Converter
• Power Consumption: 15 mW
• Type: High Speed ADC
• Brand: Texas Instruments
• Shutdown: No Shutdown
• DNL - Differential Nonlinearity: 0.25 LSB
• Gain Error: 0.01 % FS
• INL - Integral Nonlinearity: 0.25 LSB
• Moisture Sensitive: Yes
• Pd - Power Dissipation: 9 mW
• Product Type: ADCs - Analog to Digital Converters
• Reference Voltage: 2.5 V to 5 V
• SFDR - Spurious Free Dynamic Range: 106 dB
• SINAD - Signal to Noise and Distortion Ratio: 96 dB
• Factory Pack Quantity: 250
• Subcategory: Data Converter ICs
• THD - Total Harmonic Distortion: - 101 dB
• Unit Weight: 0.001566 oz
