| Mfr. #: | LM5109BMAX |
|---|---|
| Manufacturer: | Texas Instruments |
| Description: | Gate Drivers High Voltage 1A Peak Half Bridge Gate Driver 8-SOIC -40 to 125 |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | LM5109BMAX Datasheet |
This product is manufactured by Texas Instruments. This device belongs to the High Side, Low Side type. The product can operate at a maximum temperature of SMD/SMT. SOIC-8 Narrow package/case type is utilized by this product. 2 Output is the number of outputs provided by this product. Output current: 1 A Rise Time is 15 ns. 15 ns fall time Supply Voltage - Min: 8 V Supply Voltage - Max: 14 V Maximum propagation delay: 32 ns The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. Reel packaging for easy dispensing The height of the product is 1.45 mm. 4.9 mm long Texas Instruments is a trusted brand for quality electronics TTL. 2 ns maximum turn-off delay time The 2 ns. Gate Drivers product type 2500 of 100 PMIC - Power Management ICs as subcategory 1. 0.005044 oz of Unit Weight
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
LM5109BMAX Specifications
