| Mfr. #: | ADS7812PB |
|---|---|
| Manufacturer: | Texas Instruments |
| Description: | Analog to Digital Converters - ADC Low-Power Serial 12-Bit Sampling |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | ADS7812PB Datasheet |
Product belongs to the ADS7812 series. This product is categorized as Analog to Digital Converters Type: S/H ADC Tube is the packaging method for this product Weight of 0.037172 oz Through Hole Mounting-Style PDIP-16 The Single Ended for this product is CMOS/TTL. Operational temperature range: -40°C ~ 85°C Number of channels: 1 Channel Supplier device package: 16-PDIP This product's 40k. Data-Interface: SPI 12 bits The Voltage-Supply-Analog is 5V. The Voltage Supply Digital for this product is 5V. Configuration S/H-ADC The architecture of this product is SAR . External, Internal is the reference type. 1 units Power-off control: No Shutdown Power-off control: 35 mW Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C Serial SPI interface type Signal-to-Noise Ratio of 74 dB Number-of-Converters: 1 Converter 40 kS/s Sampling Rate Analog supply voltage: 5 V Digital Supply Voltage: 5 V Integral Nonlinearity: 0.5 LSB Reference voltage is 2.5 V . Differential nonlinearity: 0.5 LSB SFDR: 98 dB Signal-to-Noise-and-Distortion-Ratio: 72 dB Total Harmonic Distortion: - 96 dB Full power bandwidth of 600 kHz
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ADS7812PB Specifications
