DRV104PWP

DRV104PWP Overview

Product belongs to the DRV104 series. This product is categorized as Electromechanical Drivers Type: PWM High Side Driver Tube Alternate Packaging is the packaging method for this product Weight of 0.002046 oz SMD/SMT Mounting-Style Wide - 40 C to + 85 C operating temperature range for diverse applications HTSSOP-14 The Non-Inverting for this product is CMOS/TTL. Operational temperature range: -55°C ~ 125°C (TA) Output-Type: - Interface: On/Off Supplier device package: 14-HTSSOP The Ratio-Input:Output for this product is 1899/12/30 1:01:00. Number-of-Outputs: 1 Supply Voltage: Not Required The High Side. The -. Voltage-Load range is 8 V ~ 32 V. Our product delivers a 1.2A of 50mA for efficient power management. The Switch-Type is Relay, Solenoid Driver. This product operates at a 8 V to 32 V supply voltage for reliable performance. 1 mA is 92 nA. This product is rated for 8 V to 32 V load voltage for versatile use. Output current: 1.2 A

DRV104PWP Image

DRV104PWP Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Power Distribution Switches, Load Drivers
• Series DRV104
• Product Electromechanical Drivers
• Type PWM High Side Driver
• Packaging Tube Alternate Packaging
• Unit-Weight 0.002046 oz
• Mounting-Style SMD/SMT
• Operating-Temperature-Range - 40 C to + 85 C
• Package-Case HTSSOP-14
• Input-Type Non-Inverting
• Operating-Temperature -55°C ~ 125°C (TA)
• Output-Type -
• Features Internal PWM, Status Flag
• Interface On/Off
• Supplier-Device-Package 14-HTSSOP
• Ratio-Input:Output 1899/12/30 1:01:00
• Number-of-Outputs 1
• Voltage-Supply-Vcc-Vdd Not Required
• Fault-Protection Current Limiting (Fixed), Over Temperature
• Output-Configuration High Side
• Rds-On-Typ -
• Voltage-Load 8 V ~ 32 V
• Current-Output-Max 1.2A
• Switch-Type Relay, Solenoid Driver
• Operating-Supply-Voltage 8 V to 32 V
• Operating-Supply-Current 1 mA
• Load-Voltage-Rating 8 V to 32 V
• Output-Current 1.2 A
