DRV3204QPHPQ1

DRV3204QPHPQ1 Overview

Product belongs to the Automotive, AEC-Q100 series. This product is categorized as Brushless DC Motor Controllers Type: 3 Phase Brushless Motor Driver Tube is the packaging method for this product Weight of 0.004744 oz SMD/SMT Mounting-Style Wide - 40 C to + 150 C operating temperature range for diverse applications HTQFP-48 - is the technology used. Operational temperature range: -40°C ~ 125°C (TA) Surface Mount mounting type Product function is Controller - Commutation, Direction Management. Versatile Automotive applications for maximum usability Interface: SPI Voltage Supply Range: 5.3 V ~ 26.5 V Supplier device package: 48-HTQFP (7x7) Number-of-Outputs: 1 Output The Pre-Driver - Half Bridge (3). Voltage-Load range is -. Brushless DC (BLDC) motor type is used for high-performance and efficient operation. This product operates at a 5.3 V to 26.5 V supply voltage for reliable performance. Output voltage: 1.35 V 18 mA is 92 nA. Output current: 1.5 A The DRV3204EVM.

DRV3204QPHPQ1 Image

DRV3204QPHPQ1 Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - Motor Drivers, Controllers
• Series Automotive, AEC-Q100
• Product Brushless DC Motor Controllers
• Type 3 Phase Brushless Motor Driver
• Packaging Tube
• Unit-Weight 0.004744 oz
• Mounting-Style SMD/SMT
• Operating-Temperature-Range - 40 C to + 150 C
• Package-Case HTQFP-48
• Technology -
• Operating-Temperature -40°C ~ 125°C (TA)
• Mounting-Type Surface Mount
• Function Controller - Commutation, Direction Management
• Applications Automotive
• Interface SPI
• Voltage-Supply 5.3 V ~ 26.5 V
• Supplier-Device-Package 48-HTQFP (7x7)
• Number-of-Outputs 1 Output
• Current-Output -
• Output-Configuration Pre-Driver - Half Bridge (3)
• Voltage-Load -
• Motor-Type-Stepper -
• Motor-Type-AC-DC Brushless DC (BLDC)
• Step-Resolution -
• Operating-Supply-Voltage 5.3 V to 26.5 V
• Output-Voltage 1.35 V
• Operating-Supply-Current 18 mA
• Output-Current 1.5 A
• Development-Kit DRV3204EVM
