E-L6219 Overview

Product belongs to the L6219 series. This product is categorized as Stepper Motor Controllers / Drivers Type: Stepper Motor Controller Tube is the packaging method for this product Weight of 0.131925 oz Through Hole Mounting-Style Wide - 20 C to + 85 C operating temperature range for diverse applications PDIP-24 - is the technology used. Operational temperature range: -20°C ~ 150°C (TJ) Through Hole mounting type Product function is Driver - Fully Integrated, Control and Power Stage. Versatile General Purpose applications for maximum usability Interface: Parallel Voltage Supply Range: 4.75 V ~ 5.25 V Supplier device package: 24-PowerDIP The Half Bridge (4). Voltage-Load range is 10 V ~ 46 V. Brushed DC motor type is used for high-performance and efficient operation. This product operates at a 10 V to 46 V supply voltage for reliable performance. 15 mA is 92 nA.

E-L6219 Image

E-L6219 Specifications

• Manufacturer STMicroelectronics
• Product Category PMIC - Motor Drivers, Controllers
• Series L6219
• Product Stepper Motor Controllers / Drivers
• Type Stepper Motor Controller
• Packaging Tube
• Unit-Weight 0.131925 oz
• Mounting-Style Through Hole
• Operating-Temperature-Range - 20 C to + 85 C
• Package-Case PDIP-24
• Technology -
• Operating-Temperature -20°C ~ 150°C (TJ)
• Mounting-Type Through Hole
• Function Driver - Fully Integrated, Control and Power Stage
• Applications General Purpose
• Interface Parallel
• Voltage-Supply 4.75 V ~ 5.25 V
• Supplier-Device-Package 24-PowerDIP
• Current-Output 750mA
• Output-Configuration Half Bridge (4)
• Voltage-Load 10 V ~ 46 V
• Motor-Type-Stepper Bipolar
• Motor-Type-AC-DC Brushed DC
• Step-Resolution 1, 1/2
• Operating-Supply-Voltage 10 V to 46 V
• Operating-Supply-Current 15 mA
