| Mfr. #: | ESDA5-1BF4 |
|---|---|
| Manufacturer: | STMicroelectronics |
| Description: | TVS DIODE 5V 11V 0201 |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | ESDA5-1BF4 Datasheet |
Product belongs to the ESDA5 series. Type: Zener Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style This product's Termination-Style is ' SMD/SMT ' for easy integration into your design. The Height of the product is 0.3 mm. 0.6 mm length of the product The 0.3 mm is at most 7.6 mm. 0201 (0603 Metric) Operational temperature range: -40°C ~ 150°C (TJ) Surface Mount mounting type Versatile General Purpose applications for maximum usability Supplier device package: 201 1 Bidirectional-Channels The Voltage-Reverse-Standoff-Typ is set at a maximum of 5V. The Voltage-Breakdown-Min is 5.8V. No Power-Line-Protection 45pF @ 1MHz Capacitance-Frequency Power-off control: 110 W Maximum operating temperature of + 150 C Minimum operating temperature: - 40 C Breakdown-Voltage: 5.8 V Clamping-Voltage: 11 V 10 A Peak Surge Current 5 V working voltage Polarity: Bidirectional
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
ESDA5-1BF4 Specifications
