LP3936SLX

LP3936SLX Overview

Product belongs to the - series. Type: DC DC Regulator Tape & Reel (TR) is the packaging method for this product 32-WFQN, CSP This product's 1MHz range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Versatile Backlight, Camera Flash applications for maximum usability Supplier device package: 32-TCSP (5.5x4.5) Number-of-Outputs: 9 Current-Output-Channel is 25mA, 120mA (Flash) This product has Yes. Topology: Step-Up (Boost) feedback The maximum voltage supply is 6V. The minimum 3V required for voltage supply. Output voltage: 5.3V Dimming control is done through PWM communication.

LP3936SLX Image

LP3936SLX Specifications

• Manufacturer Texas Instruments
• Product Category PMIC - LED Drivers
• Series -
• Type DC DC Regulator
• Packaging Tape & Reel (TR)
• Package-Case 32-WFQN, CSP
• Frequency 1MHz
• Operating-Temperature -40°C ~ 85°C (TA)
• Mounting-Type Surface Mount
• Applications Backlight, Camera Flash
• Supplier-Device-Package 32-TCSP (5.5x4.5)
• Number-of-Outputs 9
• Current-Output-Channel 25mA, 120mA (Flash)
• Internal-Switch-s Yes
• Topology Step-Up (Boost)
• Voltage-Supply-Max 6V
• Voltage-Supply-Min 3V
• Voltage-Output 5.3V
• Dimming PWM
