PLL1707DBQ

PLL1707DBQ Overview

Product belongs to the PLL1707 series. Type: PLL Multi-Clock Generator Tube Alternate Packaging is the packaging method for this product Weight of 0.004437 oz SMD/SMT Mounting-Style SSOP-20 Operational temperature range: -25°C ~ 85°C Surface Mount mounting type Output-Type: CMOS Voltage Supply Range: 2.7 V ~ 3.6 V Supplier device package: 20-SSOP/QSOP Input type: CMOS, Crystal The CMOS. 1 is 8. The Ratio-Input:Output for this product is 1899/12/30 1:06:00. Differential input and output are both available: No/No Maximum frequency of 36.864MHz Yes/No Divider-Multiplier Number-of-Outputs: 6 Output Maximum operating temperature of + 85 C Minimum operating temperature: - 25 C This product operates at a 3.3 V supply voltage for reliable performance. 19 mA is 92 nA. Maximum-Input-Frequency: 27 MHz Maximum duty cycle of 55 % Maximum output frequency is 36.86 MHz. The jitter is 50 ps.

PLL1707DBQ Image

PLL1707DBQ Specifications

• Manufacturer Texas Instruments
• Product Category Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
• Series PLL1707
• Type PLL Multi-Clock Generator
• Packaging Tube Alternate Packaging
• Unit-Weight 0.004437 oz
• Mounting-Style SMD/SMT
• Package-Case SSOP-20
• Operating-Temperature -25°C ~ 85°C
• Mounting-Type Surface Mount
• Output-Type CMOS
• Voltage-Supply 2.7 V ~ 3.6 V
• Supplier-Device-Package 20-SSOP/QSOP
• PLL Yes
• Input CMOS, Crystal
• Output CMOS
• Number-of-Circuits 1
• Ratio-Input:Output 1899/12/30 1:06:00
• Differential-Input:Output No/No
• Frequency-Max 36.864MHz
• Divider-Multiplier Yes/No
• Number-of-Outputs 6 Output
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 25 C
• Operating-Supply-Voltage 3.3 V
• Operating-Supply-Current 19 mA
• Maximum-Input-Frequency 27 MHz
• Duty-Cycle-Max 55 %
• Max-Output-Freq 36.86 MHz
• Jitter 50 ps
