PTH03030WAD

PTH03030WAD Overview

Product belongs to the PTH03030W series. This product is categorized as Non-Isolated / POL Type: Non-Isolated PoL Module Tray is the packaging method for this product Through Hole Mounting-Style Trade name: POLA. Wide - 40 C to + 85 C operating temperature range for diverse applications The Height of the product is 0.354 in. 1.37 in length of the product The 1.12 in is at most 7.6 mm. 13-DIP Module Operational temperature range: -40°C ~ 85°C Through Hole mounting type Output-Type: Single Versatile ITE (Commercial) applications for maximum usability Number-of-Outputs: 1 Our product delivers a 30A of 50mA for efficient power management. The minimum input voltage is 2.95V. The 3.65V. This product is designed with - voltage isolation for maximum safety and reliability. 0.8 ~ 2.5 V output voltage Our product measures 1.37 in x 1.12 in x 0.354 in in dimensions for compact and convenient use. Input Voltage Range: 2.95 V to 3.65 V 0.8 V to 2.5 V output voltage for channel 1 Current output of channel 1 is 30 A . 1.37 in x 1.12 in x 0.354 in package-case-size

PTH03030WAD Image

PTH03030WAD Specifications

• Manufacturer Texas Instruments
• Product Category DC DC Converters
• Series PTH03030W
• Product Non-Isolated / POL
• Type Non-Isolated PoL Module
• Packaging Tray
• Mounting-Style Through Hole
• Tradename POLA
• Operating-Temperature-Range - 40 C to + 85 C
• Height 0.354 in
• Length 1.37 in
• Width 1.12 in
• Package-Case 13-DIP Module
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Through Hole
• Output-Type Single
• Features Remote On/Off, OTP, SCP, UVLO
• Size-Dimension 1.37" L x 1.12" W x 0.35" H (34.8mm x 28.4mm x 8.9mm)
• Applications ITE (Commercial)
• Number-of-Outputs 1
• Current-Output-Max 30A
• Voltage-Input-Min 2.95V
• Voltage-Input-Max 3.65V
• Voltage-Isolation -
• Output-Power 75 W
• Voltage-Output-1 0.8 ~ 2.5 V
• Voltage-Output-2 -
• Voltage-Output-3 -
• Efficiency 0.93
• Power-Watts-Manufacture-Series 75W
• Dimensions 1.37 in x 1.12 in x 0.354 in
• Input-Voltage 2.95 V to 3.65 V
• Output-Voltage-Channel-1 0.8 V to 2.5 V
• Output-Current-Channel-1 30 A
• Package-Case-Size 1.37 in x 1.12 in x 0.354 in
