| Mfr. #: | SN74LV244AMDWREP |
|---|---|
| Manufacturer: | Texas Instruments |
| Description: | Buffers & Line Drivers Mil Enhance Octal Buffers/Drivers |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | SN74LV244AMDWREP Datasheet |
Product belongs to the 74LV series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.017662 oz SMD/SMT Mounting-Style SOIC-20 Operational temperature range: -55°C ~ 125°C Surface Mount mounting type Output-Type: 3-State Number of channels: 8 Voltage Supply Range: 2 V ~ 5.5 V Supplier device package: 20-SOIC 2 element Buffer/Line Driver, Non-Inverting logic type 4 bits per element Maximum operating temperature of + 125 C Minimum operating temperature: - 55 C Polarity: Non-Inverting This product is also known as V62/06604-01XE and can be referred to by either part number. Maximum supply voltage of 5.5 V Minimum supply voltage is 2 V LV logic type 15.3 ns at 2 V 11.9 ns at 3.3 V 7.5 ns at 5 V is 23 microseconds. High-Level-Output-Current of - 16 mA 16 mA low-level output current Number-of-Input-Lines: 8 Input Number-of-Output-Lines: 8 Output
Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
SN74LV244AMDWREP Specifications
