| Mfr. #: | STPS0520Z |
|---|---|
| Manufacturer: | STMicroelectronics |
| Description: | DIODE SCHOTTKY 20V 500MA SOD123 |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | STPS0520Z Datasheet |
Product belongs to the STPS0520Z series. This product is categorized as Schottky Rectifiers Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.001058 oz SMD/SMT Mounting-Style SOD-123 Si is the technology used. Surface Mount mounting type Supplier device package: SOD-123 Configuration Single Operating frequency: Fast Recovery = 200mA (Io) Schottky diode type The 150μA @ 20V Current-Reverse-Leakage-Vr 1. Vf Max 385mV @ 500mA is the Voltage-Forward; Maximum DC reverse voltage 20V The 500mA Current-Average-Rectified-Io; The capacitance value of this product is - for maximum efficiency. Operating-Temperature-Junction: 125°C (Max) Maximum operating temperature of + 125 C Minimum operating temperature: - 65 C Vf-Forward-Voltage: 0.385 V Ir-Reverse-Current is 150 uA. If-Forward-Current is 0.5 A. VRRM (20 V) Reverse Voltage 5.5 A IFSM Forward Surge Current
