| Mfr. #: | STPS1L20MF |
|---|---|
| Manufacturer: | STMicroelectronics |
| Description: | DIODE SCHOTTKY 20V 1A STMITEFLAT |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | STPS1L20MF Datasheet |
Product belongs to the STPS1L20MF series. This product is categorized as Schottky Rectifiers Digi-ReelR Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style DO-222AA Si is the technology used. Surface Mount mounting type Supplier device package: STmite Flat Configuration Single Operating frequency: Fast Recovery = 200mA (Io) Schottky diode type The 75μA @ 20V Current-Reverse-Leakage-Vr 1. Vf Max 430mV @ 1A is the Voltage-Forward; Maximum DC reverse voltage 20V The 1A Current-Average-Rectified-Io; The capacitance value of this product is - for maximum efficiency. Operating-Temperature-Junction: 150°C (Max) Maximum operating temperature of + 150 C Minimum operating temperature: - 65 C Vf-Forward-Voltage: 0.6 V at 4 A Ir-Reverse-Current is 75 uA. If-Forward-Current is 1 A. VRRM (20 V) Reverse Voltage 50 A IFSM Forward Surge Current
