| Mfr. #: | TL431BQLP |
|---|---|
| Manufacturer: | Texas Instruments |
| Description: | Voltage References Adjustable Precision Shunt Regulato |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | TL431BQLP Datasheet |
Product belongs to the TL431B series. Bulk Alternate Packaging is the packaging method for this product Weight of 0.007520 oz Through Hole Mounting-Style TO-92-3 Operational temperature range: -40°C ~ 125°C (TA) Through Hole mounting type Output-Type: Adjustable Supplier device package: TO-92-3 Tolerance of ±0.5% - voltage input This product has a - of 200μA. Shunt is the reference type. Minimum fixed output voltage is 2.495V . 34 PPM / C is 30 parts per million per degree Celsius. - of noise in 0#1Hz-to-10Hz range Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Output voltage: Adjustable Initial accuracy: 0.5 % Maximum input voltage of 37 V for Series VREF. Maximum shunt current of 100 mA Maximum output voltage is 36 V . This product has a minimum 600 uA of 50 uA.
