| Mfr. #: | TLC5923DAP |
|---|---|
| Manufacturer: | Texas Instruments |
| Description: | LED Display Drivers 16 Ch LED Driver w/Dot Correction |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | TLC5923DAP Datasheet |
Product belongs to the TLC5923 series. Type: Linear Tube Alternate Packaging is the packaging method for this product Weight of 0.006388 oz SMD/SMT Mounting-Style HTSSOP-32 This product's 30MHz range is 0Hz to 2.2GHz. Operational temperature range: -40°C ~ 85°C (TA) Surface Mount mounting type Versatile Backlight applications for maximum usability Supplier device package: 32-HTSSOP Number-of-Outputs: 16 Current-Output-Channel is 80mA This product has Yes. Topology: Shift Register feedback The maximum voltage supply is 5.5V. The minimum 3V required for voltage supply. Output voltage: 17V Dimming control is done through - communication. Power-off control: 3.9 W Maximum operating temperature of + 85 C Minimum operating temperature: - 40 C This product operates at a 3 V to 5.5 V supply voltage for reliable performance. Maximum supply current: 65 mA High-Level-Output-Current of - 1 mA 1 mA low-level output current
