| Mfr. #: | UCC2895MDWREP |
|---|---|
| Manufacturer: | Texas Instruments |
| Description: | Switching Controllers Mil Enh BiCMOS Adv Ph Shift PWM Cntrl |
| Lifecycle: | New from this manufacturer. |
| Datasheet: | UCC2895MDWREP Datasheet |
Product belongs to the UCC2895-EP series. Digi-ReelR Alternate Packaging is the packaging method for this product Weight of 0.020106 oz SMD/SMT Mounting-Style SOIC-20 Wide Operational temperature range: -55°C ~ 150°C (TJ) * mounting type Supplier device package: 20-SOIC Number-of-Outputs: 4 Output Output-Isolation: Isolated This product has No. Topology: Full-Bridge feedback Supply Voltage: 10 V ~ 16.5 V This product features 'Frequency-Switching' at 1MHz for optimal performance. The Control-Features include Frequency Control, Soft Start, Sync function. Maximum operating temperature of + 125 C Minimum operating temperature: - 55 C Output current: 100 mA Switching frequency is 527 kHz This product has a 20 ns of 16 ns. This product has a 20 ns of 16 ns. This product is also known as V62/06614-01XE and can be referred to by either part number. Maximum duty cycle of 100 %
